Difficulty Level

Tools/Supplies Needed:

• nylon trim tool
• T15 torx screwdriver
• T25 torx screwdriver
• T27 torx screwdriver

Procedure:

• first start by removing the door lock pull by unscrewing it
• next remove the door handle pull by pulling straight up
• remove the leather padded insert, start from the one side and unclip it, there are three clips altogether
• unclip the speaker panel
• remove the speaking by removing the four T15 torx screws
• pull the speaker out and disconnect the electrical connector on the backside
• remove the two T27 torx screws from where the leather padded insert was located
• on the door jamb side towards the bottom, remove the small expanding clip
• remove four T25 torx screws located on the bottomed of the panel
• pull the door panel upward clearing both the door handle pull and the door lock pull, also insert the wires for the speaker back inside the door panel
• place the door panel in a safe location
• reassembly in reverse of disassembly
